Hikvision DS-K1102AM  Series Card Reader: Secure and Versatile Access Control The Hikvision DS-K1102AM card reader, part of the Pro 1102A Series, is a robust solution for access control systems, particularly those utilizing M1 cards. Let’s delve into its key features: Mifare Card Compatibility: This specific model, the DS-K1102AM, excels at reading M1 cards operating at 13.56 MHz frequency (M1 card, 13.56 MHz). M1 cards offer enhanced security features compared to standard EM cards, making them ideal for access control in areas requiring higher protection. Multi-protocol Communication: The reader seamlessly integrates with existing systems using either RS-485 or Wiegand protocols (W26/W34) Hikvision Series Card Reader Built-in audible beeper RS-485 and Wiegand (W26/ W34) protocol Tamper-proof alarm Supports reading EM card (Frequency: 125 KHz) (DS-K1102AE/DS-K1102AEK/DS-1102AEM) Supports reading M1 card (Frequency: 13.56 MHz). (DS-K1102AM/DS-K1102AMK/DS-K1102AEMK) Specifications Authentication Card Reading Frequency DS-K1102AE/DS-K1102AEK/DS-K1102AEM/DS-K1102AEMK: 125 KHz DS-K1102AM/DS-K1102AMK/DS-K1102AEM/DS-K1102AEMK: 13.56 MHz General Power Supply12 VDC, 500 mA Power Consumption≤ 2 W Working Temperature-20 °C to 65 °C (-4 °F to 149 °F) Working Humidity10% to 90% (no condensing) Dimensions121 mm × 86.5 mm × 14 mm (4.76″ × 3.41″ × 0.55″) InstallationApplied for 86 & 120 gang box Weight≤ 0.14 kg (0.3 lb) Keypad DS-K1102AE/DS-K1102AM/DS-K1102AEM: No Keypad DS-K1102AEK/DS-K1102AMK/DS-K1102AEMK: Keypad with 12 keys (0 to 9, *, #) BuzzerBeeper Function ID Settingsvia DIP switch   Show More Show Less
